ILL-SL05

Spotlight

Short Description

The ILL-SL0XX05 Narrow Beam Spotlight is a high-performance lighting solution featuring a narrow beam angle. This spotlight offers precise illumination and highlights specific objects, architectural features, or display areas. Excellent heat management ensures the spotlight operates efficiently, even after extended use, contributing to a longer lifespan and enhanced performance. Suitable for use as accent lighting in living rooms, dining areas, or exhibition spaces to highlight focal points and create visual interest. With different reflector finishes this modern and compact design of the spotlight complements various  ceiling finishes  and can be seamlessly integrated into different lighting schemes.

GENERAL INFORMATIONS
Model No- ILL-SL0XX05 Series
Application Area-Indoor
Product Family-Spot Light
Material and Finish (Body)-Die -Cast Aluminium, White, Black.
Material and Finish (Reflector)-Matt White, Matt Black, Silver, Gold
IP Level-IP20/44
Working temperature- -20°C~50°C
Working hours-50000 Hrs.

ELECTRICAL PARAMETERS
Input voltage-120-270 VAC, 50/60 Hz
Power-10W,15W,20W,30W
Control Type-On/ Off , Dimmable

OPTICAL PARAMETERS
Light Source-LED COB
Colour Temperature (CCT)-2700K - 6500K
Colour Rendering Index (CRI) ->80,>90
Beam Angle-15°,30°,45°
Luminous output-100lm/W ( ± 5 %)

WARRANTY
5 years Warranty

CERTIFICATES
CE


Specification

ILL-SL01005
:

10W-1000lm-Ø85xH59-Ø75

ILL-SL01505
:

15W-1500lm-Ø105xH71-Ø95

ILL-SL02005
:

20W-2000lm-Ø130xH86-Ø120

ILL-SL03005
:

30W -3000lm-Ø150xH93-Ø140
