ILL-SL02

Short Description

The SL02 Adjustable spotlights are versatile and highly functional lighting fixtures designed to provide directional illumination with the ability to adjust the angle of the light beam. These spotlights are ideal for various applications, from accent lighting to task lighting, in both residential and commercial settings. Their adjustable nature allows for customizable lighting, making them perfect for highlighting specific areas, objects, or architectural features.


GENERAL INFORMATIONS

Model No. ILL-SL0XX02 Series

Product Family-Spot Light

Application Area-Indoor

Material and Finish (Body)-Die -Cast Aluminum, White,Black

Material and Finish (Reflector)-Silver,White,Black,Golden

IP Level-IP20/IP44 Available

Working temperature- -20°C~50°C

Working hour-50000 Hrs

ELECTRICAL PARAMETERS

Input voltage-120-270 VAC, 50/60 Hz

Power-8W,15W,25W,35W,55W

Control Type-On/ Off , Dimmable

OPTICAL PARAMETERS

Light Source-LED COB

Colour Temperature (CCT)-2700K - 6500K

Colour Rendering Index (CRI)->80,>90

Beam Angle-15°, 24°, 36°,60°

Luminous output-100lm/W ( ± 5 %)

WARRANTY

5 years Warranty

CERTIFICATES

CE


Specification

ILL-SL00802
:

8W -800lm-Ø62*H75-Ø55

ILL-SL01502
:

15W-1500lm-Ø85*H89-Ø75

ILL-SL02502
:

25W-2500lm-Ø104*H115-Ø95

ILL-SL03502
:

35W-3500lm-Ø140*H149-Ø120

ILL-SL05502
:

55W-5500lm-Ø168*H179-Ø145
