ILL-DL03

Downlights

Short Description

The ILL-DL0XX03 Series Downlight is a high-performance, energy-efficient recessed lighting solution for residential and commercial spaces. ILL-DL0XX03 Series comes with premium LED Technology that delivers bright, consistent lighting while consuming less energy, providing long-lasting, cost-effective performance. Built for durability, the ILL-DL0XX03 Series is designed to last for many years, reducing the need for frequent replacements and lowering maintenance costs. The ILL-DL0XX03 Series ensures smooth, even light distribution, eliminating harsh shadows or hot spots, ideal for ambient lighting.

GENERAL INFORMATIONS

Model No-ILL-DL0XX03 Series

Product Family-Downlight

Application Area-Indoor

Material and Finish (Body)-Die -Cast Aluminium, White, Black

IP Level- IP20/54

Working temperature- -20°C~50°C

Working hour- 50000 Hrs

ELECTRICAL PARAMETERS

Input voltage-120-270 VAC, 50/60 Hz

Power- 18W,25W

Control Type-On/ Off , Dimmable

OPTICAL PARAMETERS

Light Source- LED SMD

Colour Temperature (CCT)- 2700K - 6500K

Colour Rendering Index (CRI)- >80,>90

Beam Angle- 100°

Luminous output- 110lm/W ( ± 5 %)

WARRANTY

5 years Warranty

CERTIFICATES

CE , TUV

Specification

ILL-DL01803
:

18W- 1980lm- Ø178xH51.5

ILL-DL02503
:

25W- 2750lm- Ø178xH51.5
