ILL-SDL15
Short Description
GENERAL INFORMATIONS
Model No. ILL-SDL0XX15 Series
Product Family-Surface Mount Downlight
Application Area-Indoor
Material and Finish (Body)-Die -Cast Aluminum, White, Black
Material and Finish (Reflector)-Not Applicable
IP Level-IP20
Working temperature--20°C~50°C
Working hour-50000 Hrs
ELECTRICAL PARAMETERS
Input voltage-120-270 VAC, 50/60 Hz
Power-20W,24W,40W,45W,50W,80W,100W
Control Type-On/ Off , Dimmable
OPTICAL PARAMETERS
Light Source-LED SMD
Color Temperature (CCT)-2700K - 6500K
Color Rendering Index (CRI)->80,>90
Beam Angle-110°
Luminous output-75lm/W ( ± 5 %)
WARRANTY
5 years Warranty
CERTIFICATES
CE
